Technical Features
– Proprietary CD drive system mounted on our M-Quattro gel-based 4-point floating suspension
for vibration damping, allowing ambient & spatial cues in your recordings to come to life like
never before;
– Two (2) digital outputs: S/PDIF and AES/EBU.
– Oversized power supply with up to 13 stages of voltage regulation
(5 for Transport and 8 for the DAC)
– RS-232 port for (i) full unsolicited bidirectional feedback and (ii) firmware updates
– IR input for external control
– SimLink™ controller port for 2-way communications with other compatible MOON components
– Rigid chassis construction to minimize the effects of external vibrations
– Optimized selection of very high quality electronic components in a symmetrical circuit design
– Includes CRM-2 remote control.
With Optional Digital-to-Analog Converter
– True 32-bit asynchronous Digital-to-Analog converter
– Four (4) digital inputs (S/PDIF x 2, TosLink x 1 & USB x 1) allowing for use with virtually any
digital source.
– Advanced analog signal path using a DC servo circuit and proprietary 18dB/octave analog filter
– USB input with galvanic isolation which eleminates all ground current (i.e. no electrical
connection) between the USB device (computer, music server, etc.) and the 260D, preserving
the accuracy of the audio signal
Configuration: | Single-ended |
Front Panel Controls: | Standby · Program · Display · Repeat · Input · Random · Time · Open/Close · Play · Pause · Scan/Skip Forward · Scan/Skip Backward · Stop |
Front Panel Display: | Track number · Time – elapsed or remaining (track / disc) · Sampling Frequency Rate |
Front Panel LED Indicators: | Program · Repeat – current track · Repeat – entire disc · Random |
Digital Outputs: | 2 AES/EBU (XLR) S/PDIF (RCA) |
SimLink™ Port: | 1 input + 1 output each on 1/8″ mini-jack |
RS-232 Port: | 9-pin female DB connector |
IR input: | 1/8″ mini-jack |
Remote Control: | CRM-2 Full Function |
Power Consumption in Standby: | 0.5 watts |
AC Power Requirements: | 120V / 60Hz 220-240V / 50Hz |
Optional Digital-to-Analog Converter | |
DAC / Digital Filter: | Asynchronous 32-bit |
Frequency Response (full range): | 2Hz – 100kHz +0/-3dB (external source) |
THD @ 1kHz, 0dBFS (A-weighted): | < 0.001 % |
IMD: | < 0.001 % |
Dynamic Range: | > 120dB |
Signal-to-noise ratio: | > 120dB @ full output |
Channel Separation: | > 116dB |
Low Level Linearity: | < ±0.25dB at -90dBFS |
Intrinsic Jitter: | < 1 picosecond RMS |
Analog Outputs: | Balanced 1 pair XLR Single-Ended 1 pair RCA |
Analog Output Impedance: | (XLR/RCA) 75Ω |
Max. Analog Output @ 0dBFS: | 2.0 Volts (XLR/RCA) |
Bit-depth range: | 16 – 24 bits |
Sampling Frequency Rate range: | 44.1 – 192kHz (up to 96kHz for TosLink) |
Digital Inputs (4): | USB x 1 TosLink x 1 S/PDIF (RCA) x 2 |
Gewicht: | 7.5 Kg |
Breedte: | 42,9 cm |
Hoogte: | 8,6 cm |
Diepte: | 33,3 cm |
